smtp authentication with port 25 & 587 not working

get-help
1

getting following errors
``
SMTP Error: Could not connect to SMTP host. Connection failed. stream_socket_enable_crypto(): SSL operation failed with code 1. OpenSSL Error messages:
error:1416F086:SSL routines:tls_process_server_certificate:certificate verify failed
Message could not be sent. Mailer Error: SMTP Error: Could not connect to SMTP host. Connection failed. stream_socket_enable_crypto(): SSL operation failed with code 1. OpenSSL Error messages:
error:1416F086:SSL routines:tls_process_server_certificate:certificate verify failedSMTP server error: QUIT command failed Detail: cIĝh6H az)N&(o҆3PJpzn~ƌ!uS&BXkrOHڴxz]oEobpOlkgRPÊ%mX=NZXU"d>_L0T.zHSkxk5S-,Dq BFڈF,tQ3w48gn*b&9~R6E

``

2

https://gist.github.com/mailergeek/4c9e66cbdd5553bb555e459310c2a983

do find the config which i had used

3

How was the error encountered? What client connecting to what host? Which produced the error?

4

it was done though the standard phpmailer connection through smtp connection.

5

Do you have a trace?

6
7

[2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 0ns === Connected 2023-11-24 15:54:55.532224578 UTC [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 0ns === conn_meta received_from="2xx.xxx.xx.xx:40422" [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 0ns === conn_meta received_via="1xx.x.xxx.xx:587" [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 0ns === conn_meta reception_protocol="ESMTP" [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 17µs <- 220 kumomta.abcdef.com KumoMTA [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 182ms -> EHLO kumomta.abcdef.com [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 183ms === smtp_server_ehlo: Ok [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 183ms <- 250-kumomta.abcdef.com Aloha kumomta.abcdef.com [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 183ms <- 250-PIPELINING [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 183ms <- 250-ENHANCEDSTATUSCODES [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 183ms <- 250 STARTTLS [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 588ms -> STARTTLS [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 588ms <- 220 Ready to Start TLS [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 1s -> QUIT [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 1s <- 221 So long, and thanks for all the fish! [2xx.xxx.xx.xx:40422->1xx.x.xxx.xx:587] 1s === Closed

8

Show the phpmailer code?

9

It looks like this failed at the STARTTLS which typically indicates the injection system is not using TLS or has a failed cert.
try opening a new terminal on the KumoMTA host and running the kcli server trace to see all the inbound details.

10
11

Smtp_Auth inbound MUST be secured with TLS.

12

Based on the trace, it seems like the cert didn’t verify. The binary junk your client prints out is concerning; can you try a different client to see if you get better diagnostics? in a pinch, openssl s_client -starttls smtp -crlf -connect 127.0.0.1:25 can be useful.

13
<?php use PHPMailer\PHPMailer\PHPMailer; use PHPMailer\PHPMailer\Exception; require 'vendor/autoload.php'; $mail = new PHPMailer(true); try { $mail->SMTPDebug = 2; $mail->isSMTP(); $mail->Hostname = 'kumomta.abcd.com'; $mail->Host = 'kumomta.abcd.com'; $mail->SMTPAuth = true; $mail->Username = 'abcd@abcd.in'; $mail->Password = 'QSFNLjc3JE4jZWF2NSVeITAw'; $mail->SMTPSecure = 'tls'; $mail->Port = 587; $mail->AuthType = 'PLAIN'; $mail->setFrom('abcd@kumomta.abcd.com', 'Susu'); $mail->addAddress('xyz@gmail.com'); $mail->isHTML(true); $mail->Subject = 'Subject'; $mail->Body = 'HTML message body in bold '; $mail->AltBody = 'Body in plain text for non-HTML mail clients'; $mail->send(); echo "Mail has been sent successfully!"; } catch (Exception $e) { echo "Message could not be sent. Mailer Error: {$mail->ErrorInfo}"; }
14

^^ please tell me you obfuscated that password before posting it here.

15

It may be helpful to try with swaks to see if it is really a cert issue.

16
17

Probably also a good idea to print the details from the $e exception here in case there is additional context:

} catch (Exception $e) {
        echo "Message could not be sent. Mailer Error: {$mail->ErrorInfo}";
}
18

@faithful-ostrich with open relay ip i am able to sent emails without username & password

19

Hence the concept of “open relay”

20

Please do not use an open relay. Is not necessary unless you are managing inboxes
