Configuring KumoMTA with Multiple Public IPs on Proxy Server

get-help
1

Problem Statement:

I have a server with multiple public IP addresses configured, and I am using KumoMTA to send emails through kumoproxy. On the proxy server, I have configured multiple instances of the proxy server to listen on different internal IP addresses, each corresponding to a public IP address. However, when emails are sent, the IP pool rotates inside the KumoMTA server, but the final sending IP address from the four public-facing IPs on the proxy server is always the same (IP1). With the same KumoMTA configuration, changing the proxy server IP to a single IP per proxy server works as expected, but using multiple IPs on the proxy server does not.
Current Configuration:
Proxy Server Commands:

bash

/opt/kumomta/sbin/proxy-server --listen 10.0.1.1:5000 &
/opt/kumomta/sbin/proxy-server --listen 10.0.1.2:5000 &
/opt/kumomta/sbin/proxy-server --listen 10.0.1.3:5000 &
/opt/kumomta/sbin/proxy-server --listen 10.0.1.4:5000 &

Issue Description:

Despite configuring multiple proxy server instances to listen on different internal IP addresses, the final sending IP from the four public-facing IPs on the proxy server is always the same (IP1). When configuring one IP per proxy server, the setup works as expected.

2

Hey there @original-jellyfish, thanks for posting. Please read the “Troubleshooting” and “How to Ask for Help” buttons below. If you would like a 1:1 support session from the KumoMTA team, details are at the “Book a Support Session” button below.

3

You may be overthinking this. KumoProxy can route to any public IP plumbed on the server so you only need to install it once.

In your sources.toml (or manually)

name = ‘ip-1’,

  -- The SOCKS5 proxy server address and port
  socks5_proxy_server = '10.0.1.1:5000',

  -- Used by the SOCKS5 proxy server to connect to the destination address
  socks5_proxy_source_address = '200.100.50.1',

  ehlo_domain = 'mta1.examplecorp.com',
}
4

this is the sources.toml

[source."ip-1"]
socks5_proxy_server = '10.0.1.1:5000'
socks5_proxy_source_address = '10.0.1.1'
ehlo_domain = 'r17.domain1.com'

[source."ip-2"]
socks5_proxy_server = '10.0.1.2:5000'
socks5_proxy_source_address = '10.0.1.2'
ehlo_domain = 'r18.domain1.com'

[source."ip-3"]
socks5_proxy_server = '10.0.1.3:5000'
socks5_proxy_source_address = '10.0.1.3'
ehlo_domain = 'r19.domain2.com'

[source."ip-4"]
socks5_proxy_server = '10.0.1.4:5000'
socks5_proxy_source_address = '10.0.1.4'
ehlo_domain = 'r192.domain2.com'

[pool."domain1-com-pool"]
[pool."domain1-com-pool"."ip-1"]
weight = 1
[pool."domain1-com-pool"."ip-2"]
weight = 1

[pool."domain2-com-pool"]
[pool."domain2-com-pool"."ip-3"]
weight = 1
[pool."domain2-com-pool"."ip-4"]
weight = 1
5

I tried it this way , and the behavior is I can see the routing happening correctly inside the server but in the proxy server

6

I tried it with config also

[source."ip-1"]
socks5_proxy_server = '10.0.1.1:5000'
socks5_proxy_source_address = '10.0.1.1'
ehlo_domain = 'r17.domain1.com'

[source."ip-2"]
socks5_proxy_server = '10.0.1.1:5000'
socks5_proxy_source_address = '10.0.1.2'
ehlo_domain = 'r18.domain1.com'

[source."ip-3"]
socks5_proxy_server = '10.0.1.1:5000'
socks5_proxy_source_address = '10.0.1.3'
ehlo_domain = 'r19.domain2.com'

[source."ip-4"]
socks5_proxy_server = '10.0.1.1:5000'
socks5_proxy_source_address = '10.0.1.4'
ehlo_domain = 'r192.domain2.com'

[pool."domain1-com-pool"]
[pool."domain1-com-pool"."ip-1"]
weight = 1
[pool."domain1-com-pool"."ip-2"]
weight = 1

[pool."domain2-com-pool"]
[pool."domain2-com-pool"."ip-3"]
weight = 1
[pool."domain2-com-pool"."ip-4"]
weight = 1

changes in socks5_proxy_server = ‘10.0.1.1:5000’ only

still same behaviour

7

What release? There have been recent fixes for kproxy.

8

kumod 2023.12.28-63cde9c7

this is the version

9

Move to KumoMTA-dev and update

10

will test it out and update the result
