Routing

get-help
1

Please tell me how to use routing in Kumo MTA, idea is I want that the from a different egress pool I want to send the mail to the another third party MTA which has auth enable for them

2

Hey there @youthful-zorse, thanks for posting. To ensure the fastest resolution to your issue, please review the following and follow all the steps:

3
4

I am having trouble configuring that, can you please let me know is there any example if I can use to check.

5

Other than the example in the docs? I’d rather see what you tried and how it is not working so I can improve the docs.

6

ok let me send the code

7
kumo.on('get_egress_path_config', function(domain, site_name)
  return kumo.make_egress_path {
    enable_tls = 'Required',
    smtp_auth_plain_username = 'scott',
    -- The password can be any keysource value
    smtp_auth_plain_password = {
      key_data = 'tiger',
    },
  }
end)
8

I have just use this

9

does I need to add something extra?

10

And what goes wrong?

11

And what is the full init.lua?

12

ok sharing the same

13
kumo.on('get_egress_path_config', function(domain, site_name)
  return kumo.make_egress_path {
    enable_tls = 'Required',
    smtp_auth_plain_username = 'scott',
    -- The password can be any keysource value
    smtp_auth_plain_password = {
      key_data = 'tiger',
    },
  }
end)
kumo.on('smtp_server_auth_plain', function(authz, authc, password, conn_meta)
  local password_database = {
    ['scott'] = 'tiger',
    ['scott1'] = 'tiger',
  }
  if password == '' then
    return false
  end
  return password_database[authc] == password
end)
-- Configure source IPs.
local sources = require 'policy-extras.sources'
sources:setup ({ '/opt/kumomta/etc/sources.toml' })


local queue_module = require 'policy-extras.queue'
local queue_helper =   queue_module:setup ({ '/opt/kumomta/etc/queues.toml' })


--[[ Double DKIM Sign  ]]

kumo.on('smtp_server_message_received', function(msg)
  queue_helper:apply(msg)
  local domain = msg:recipient().domain
        if (domain == "gmail.com")
          then
                local aclmobile_net_signer = kumo.dkim.rsa_sha256_signer {
                domain = 'aclmobile.net',
                selector = '5nXKKHgBnyGAcLwvMLZIq',
                headers = {'Content-Type', 'Message-Id', 'Subject', 'Date', 'Mime-Version', 'To', 'From'},
                key = '/opt/kumomta/etc/dkim/aclmobile.net/5nXKKHgBnyGAcLwvMLZIq.key',
                 }
                msg:dkim_sign(aclmobile_net_signer)
        end

 local signer = kumo.dkim.rsa_sha256_signer {
        domain = msg:from_header().domain,
        selector = 'acls01',
        headers = { 'From', 'To', 'Subject' },
        key = '/opt/kumomta/etc/dkim/acl.pinchappmails.com/acls01.key',
          }
        msg:dkim_sign(signer)

 end)
14
local kumo = require 'kumo'
--[[ Start of INIT section ]]
--

kumo.on('init', function()
  kumo.start_esmtp_listener {
    listen = '0.0.0.0:587',
  }

  kumo.define_spool {
    name = 'data',
    path = '/var/spool/kumomta/data',
  }

  kumo.define_spool {
    name = 'meta',
    path = '/var/spool/kumomta/meta',
  }

--  kumo.configure_local_logs {
  --  log_dir = '/var/log/kumomta',
  --}

  kumo.configure_local_logs {
  log_dir = '/var/log/kumomta',
  max_segment_duration = '01 seconds',
  per_record = {
    Reception = {
      -- use names like "20230306-022811_recv" for reception logs
      suffix = '_recv',
    },

    Delivery = {
      -- put delivery logs in a different directory
      log_dir = '/var/log/kumo/delivery',
      suffix = '_dev',
      --template = [[{{type}} id={{ id }}, from={{ sender }}, recipient={{ recipient }}, response={{ response_code }}, content={{ code }} peer_address={{ peer_address }}, timestamp={{ timestamp }}]],
    },

    TransientFailure = {
      -- Don't log transient failures
      enable = false,
    },

    Bounce = {
      -- Instead of logging the json record, evaluate this
      -- template string and log the result.
      --template = [[Bounce! id={{ id }}, from={{ sender }} code={{ code }} age={{ timestamp - created }}]],
      suffix = '_bounce',
    },

    -- For any record type not explicitly listed, apply these settings.
    -- This effectively turns off all other log records
    Any = {
      enable = false,
    },
  },
}

  kumo.set_diagnostic_log_filter 'kumod=debug'
  kumo.configure_local_logs {
    log_dir = '/var/log/kumomta',
  }
  kumo.configure_bounce_classifier {
    files = {
      '/opt/kumomta/share/bounce_classifier/iana.toml',
    },
  }

end)
15

this is my whole init.lua file

16

So you have no logic in your lua to say when to use the authentication. You should do like you have logic checking if the domain being passed is the one you want to authenticate to, and that local kumo = require kumo should be at the top of the init.lua

17

rather than lua, can I use toml file?

18

is there any steps

19

Look at using the shaping helper, and then you can put the credentials in the config for that domain, there’s an example in the page I linked to at the bottom on how to do it via the shaping helper.

20

ok
